Medical ventilator external oil-free air compressor
Specifications: : BW501/701/1101/1501
Type: Swing piston type
Characteristic service: Support --OEM / ODM
Voltage range: AC or DC
- Datasheet
- Typical uses
- Characteristic
| Project | BW501 | BW701 | BW1101/BW1501 | |
| Voltage/frequency
输入电压 | 1. 220-230V/50Hz
2. 220-230V/60Hz 3. 100-120V/60Hz 4. 100V/50V/60Hz 5. 380-440V 3PH 50Hz
| 1,2,3,4 optional | 1,2,3,4,5 optional | 1,2,3,4,5 optional |
| Power
功率 | KW | 0.58 | 0.78 | 1.2/1.5 |
| HP | 3/4 | 1 | 1.5/2 | |
| Volume flow
排气量 | L/min @0MPa | 120 | 175 | 250/300 |
| L/min @0.7MPa | 45 | 55 | 110/145 | |
| Pressure
压力 | Bar | 8 | 8 | 8 |
| MPa | 0.8 | 0.8 | 0.8 | |
| Tank volume
储气罐容积 | L | 25 | 25 | 50 |
| US gallons | 6.6 | 6.6 | 13 | |
| Noisy噪音 | dB | 54 | 55 | 62 |
| Pressure switch | According to customer’s requirements | |||
| Configuration optional可选配置 | 1. Add oil and water separator空气过滤器
2. Add automatic drainer自动排水 3. Antirust treatment or stainless steel gas tank inside the gas tank储气罐内部防锈处理或不锈钢储气罐 | 1,2,3 optional | 1,2,3 optional | 1,2,3 optional |
| Size外形尺寸 | L*W*H cm | 40*40*65 | 40*40*65 | 42*42*85 |
| Weight重量 | Kg | 31 | 32 | 45/46.5 |
| Packing包装尺寸 | Cartons or wooden cases size cm | Paper 42*42*68 | Paper 42*42*68 | Paper 44*44*87 |
| Main application
主要用途 | Main use: the ventilator is connected with clean compressed air, the dental treatment chair is equipped with air compressor, and the laboratory is mute and oil-free air compressor呼吸机外接清洁压缩空气，牙科治疗椅配套空压机，实验室静音无油空压机 | |||
Main use: the ventilator is connected with clean compressed air, the dental treatment chair is equipped with air compressor, and the laboratory is mute and oil-free air compressor
Lower noise, medical grade purified air, can be equipped with dew point – 70 ℃ adsorption dryer, optional with 304 stainless steel gas tank, can be equipped with remote control system.
